Module Power: Up to 420 W
Module Efficiency: Up to 21.5%
Lower LCOE and system cost
Comprehensive LID / LeTID mitigation – up to 50% lower degradation
Better shading tolerance
More Reliable Performance
- Minimizes micro-crack impacts
- Heavy snow load up to 5400 Pa
- Wind load up to 2400 Pa*
Electrical Data (STC)
- Nominal Max. Power (Pmax): 405 W
- Operating Voltage (Vmp): 31.0 V
- Operating Current (Imp): 13.07 A
- Open Circuit Voltage (Voc): 37.0 V
- Short Circuit Current (Isc): 13.93 A
- Module Efficiency: 20.7%
- Operating Temperature: -40°C to +85°C
- Power Tolerance: 0 ~ +10 W
Mechanical Specifications
- Frame Colour: Black only
- Cell Type: Mono-crystalline
- Cell Arrangement: 108 [2 × (9 × 6)]
- Dimensions: 1722 × 1134 × 30 mm
- Weight: 21.3 kg
- Front Cover: 3.2 mm tempered glass with anti-reflective coating
- Frame: Anodized aluminium alloy
- Junction Box: IP68, 3 bypass diodes
- Cable: 4 mm² (IEC), 12 AWG (UL)
- Connector: T6, MC4, MC4-EVO2, or MC4-EVO2A
- Cable Length (including connector):
- Portrait: 350 mm (+) / 250 mm (−)
- Landscape: 1100 mm (+/−)
Temperature Characteristics
- Temperature Coefficient (Pmax): -0.34% / °C
- Temperature Coefficient (Voc): -0.26% / °C
- Temperature Coefficient (Isc): 0.05% / °C
- Nominal Operating Temperature: 41 ± 3°C
