High Pressure Fire Fighter Diesel Driven – BIGBERTHA-DF1

Description

The BIGBERTHA-DF1 High Pressure Fire Fighter is a powerful and reliable diesel-driven firefighting unit designed for rapid response fire control in agricultural, forestry, industrial, and rural environments. Mounted as a portable “Bakkie Sakkie” unit, it fits securely onto the back of most pickup trucks, allowing easy mobility and quick deployment in emergency situations.

Equipped with a durable Turner Morris diesel engine and a high-performance J25 piston pump delivering up to 35 Bar pressure, this unit provides exceptional spraying power for extinguishing fires efficiently. The integrated Venturi refill system allows for convenient and fast tank refilling directly from external water sources, reducing downtime during operation.

In addition to firefighting, the BIGBERTHA-DF1 can also be used for equipment cleaning, washdown applications, and spraying insecticides, making it a versatile solution for farms, estates, municipalities, and industrial sites.

Key Features:

• 650L heavy-duty water tank
• Reliable Turner Morris diesel engine
• J25 piston pump delivering up to 35 Bar pressure
• 20m hydraulic 3/8” high-pressure hose fitted on hose reel
• Adjustable spray gun for controlled water flow
• Integrated Venturi refill system for easy tank refilling
• Large tank lid for quick and convenient access
• Baffled tank design improves stability during transport
• Portable Bakkie Sakkie design for pickup truck mounting
• Suitable for firefighting, cleaning equipment, and insecticide spraying
• Rugged construction for demanding environments

Operating Instructions:

1. Secure the Fire Fighter unit properly to the vehicle.
2. Fill the tank with water.
3. Start the diesel engine.
4. Adjust the outlet nozzle to the required spray pattern.
5. Practice safe firefighting techniques during operation.
6. Always wear the correct protective safety equipment.

Safety Information:

• This equipment may create dust — wear a suitable dust mask.
• Hand protection must be worn while operating the equipment.
• Ensure all hoses and fittings are securely connected before use.
• Never operate the pump without sufficient water in the tank.
